678nm
678nm 5mW 2835 VCSEL SMD
678nm 5mW QCW VCSEL in a 2835 SMD package with a 22° annular beam for wavelength-specific hair-growth helmet and scalp-light prototype evaluation.
Select the Products and Modules that Interest You.
Visible Red VCSELs
22 products
View Product
650nm
650nm 5mW VCSEL SMD Series
650nm 5mW VCSEL SMD series with five PCT and ceramic package options for SMT integration, hair-growth devices, PCB layouts and OEM red-light design.
680nm
680nm 50mW VCSEL Bare Die
680nm 50mW VCSEL Bare Die for die attach, gold-wire bonding, ceramic submount assembly, custom VCSEL packaging and high-output red VCSEL chip integration.
680nm
680nm 18mW VCSEL Bare Die
680nm 18mW VCSEL bare die with six emitters, 163 × 185μm die size and QCW output at 30mA for wire bonding and higher-output red-laser module integration.
680nm
680nm 12mW VCSEL Bare Die
680nm 12mW VCSEL bare die with four emitters, 170 × 170μm die size and QCW output at 20mA for wire bonding and custom red-laser module integration.
680nm
680nm 5mW VCSEL Bare Die
680nm 5mW VCSEL Bare Die for die attach, gold-wire bonding, ceramic submount assembly, custom VCSEL packaging and OEM red VCSEL chip integration.
680nm
680nm 5/12/18/50mW VCSEL Bare Die Series
680nm 5/12/18/50mW VCSEL Bare Die Series for wire bonding, ceramic submount assembly, custom laser packaging and red VCSEL chip integration projects.
680nm
680nm 5/34mW VCSEL SMD Series
680nm 5mW and 34mW peak-output QCW VCSEL SMD series in 2835, 3030 and 5730 packages for scalp PBM, localized red-light and OEM device integration.
670nm
670nm 12mW VCSEL Bare Die
670nm 12mW VCSEL bare die with six emitters, 12mW typical QCW output at 25mA and rectangular die geometry for red-light optical-module integration.
670nm
670nm 4mW VCSEL Bare Die
670nm 4mW VCSEL Bare Die for die attach, gold-wire bonding, ceramic submount assembly, custom VCSEL packaging and OEM red VCSEL chip integration.
670nm
670nm 9mW VCSEL Bare Die
670nm 9mW VCSEL bare die with four emitters and 9mW typical QCW output at 18mA for square-die red-light source packaging and optical-module integration.
670nm
670nm 4/9/12mW VCSEL Bare Die Series
670nm 4/9/12mW VCSEL Bare Die Series for wire bonding, ceramic submount assembly, custom laser packaging and red VCSEL chip integration projects.
665nm
665nm 9mW VCSEL Bare Die
665nm 9mW VCSEL Bare Die for die attach, gold-wire bonding, ceramic submount assembly, custom VCSEL packaging and 6-emitter red VCSEL chip integration.
665nm
665nm 8mW VCSEL Bare Die
665nm 8mW multi-mode VCSEL bare die with four emitters, 170 × 170μm die size and QCW output at 15mA for wire bonding and custom red laser packaging.
665nm
665nm 7mW VCSEL Bare Die
665nm 7mW multi-mode VCSEL bare die with four emitters, 170 × 170μm die size and QCW output at 18mA for wire bonding and custom red laser packaging.
665nm
665nm 3mW VCSEL Bare Die
665nm 3mW VCSEL Bare Die for die attach, gold-wire bonding, ceramic submount assembly, custom VCSEL packaging and OEM red VCSEL chip integration.
665nm
665nm 3/7/8/9mW VCSEL Bare Die Series
665nm 3/7/8/9mW VCSEL Bare Die Series for wire bonding, ceramic submount assembly, custom laser packaging and red VCSEL chip integration projects.
660nm
660nm 7mW VCSEL Bare Die
660nm 7mW VCSEL Bare Die for wire bonding, ceramic submount assembly, custom laser packaging, red VCSEL chip and custom OEM optical module integration.
660nm
660nm 5mW VCSEL Bare Die
660nm 5mW VCSEL Bare Die for die attach, wire bonding, ceramic submount assembly, custom laser packaging and red VCSEL chip integration projects.
660nm
660nm 2mW VCSEL Bare Die
660nm 2mW single-emitter VCSEL bare die for wire bonding, ceramic submount assembly, custom laser packaging and compact red-light module integration. 660nm 2mW single-emitter VCSEL bare die for wire bonding, ceramic submount assembly, custom laser packaging and compact red-light module integration.
660nm
660nm 2/5/7mW VCSEL Bare Die Series
660nm 2mW, 5mW and 7mW VCSEL bare die series with single- and multi-emitter options for wire bonding, ceramic submounts and custom laser packaging.
660nm
660nm 5/7mW VCSEL SMD Series
660nm 5mW and 7mW VCSEL SMD series in 2016, 2835, 3030 and 5730 packages for beauty masks, hair-growth devices, PCB integration and OEM optical design.
